TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | IR800.4 – 2 OHMS |
|---|---|
| Number of Channels | 4 |
| RMS Power | 800W |
| RMS Power at 2 Ohm 12.6V | 4 x 200W (STEREO) |
| RMS Power at 4 Ohm 12.6V | 4 x 135W (STEREO) |
| RMS Power at 2 Ohm 14.4V | 4 x 265W |
| RMS Power at 4 Ohm 14.4V | 4 x 175W (STEREO) |
| Power @ 12.6V Bridge 4 Ohms | 2 x 400W (BRIDGE) |
| Power @ 13.8V Bridge 4 Ohms | 2 x 530W (BRIDGE) |
| Supply Voltage | 9V ~15,5V |
| Frequency Response | 5Hz ~ 22 KHz |
| Crossover Low Pass | 90 Hz |
| Crossover High Pass | 90 Hz |
| Signal to Noise | >80 dB |
| Input Sensitivity | RCA: 0,2V / FIO: 1,5V |
| Input Impedance | RCA: 30K Ohms / FIO: 1K Ohms |
| Impedance Output | STEREO: 2 OHMS / BRIDGE: 4 OHMS |
| Consumption with Signal Musical | 44A |
| Consumption with Signal Bass | 88A |
| Dimensions (H x W x D) mm | 55 x 162 x 235,5 mm |
| Weight Kg | 1,5 Kg |
