The BRAVO BASS line was developed for automotive sound lovers who seek maximum performance in low frequencies. Its frequency response of 8Hz to 250Hz provides powerful bass with quality and definition, for use with subwoofers and woofers.
The BRAVO BASS 1k2 model has a dedicated control to highlight the BASS BOOST bass, with variable frequency adjustment from 30Hz to 70Hz and performance of up to +10dB.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO BASS 1K2 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 1.200W |
| RMS Power at 1 Ohm 13.8V | 1.200W |
| RMS Power at 2 Ohm 13.8V | 700W |
| RMS Power at 1 Ohm 14.4V | 1.300W |
| RMS Power at 2 Ohm 14.4V | 775W |
| Supply Voltage | 9V ~ 17V DC |
| Frequency Response | 8Hz ~ 250Hz |
| Crossover Low Pass | 30Hz ~ 70Hz |
| Crossover High Pass | 8Hz ~ 40Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 0,2V ~ 3,5V |
| Input Impedance | 5K Ohms |
| Impedance Output | 1 Ohm |
| Consumption with Signal Musical | 50A |
| Consumption with Signal Bass | 100A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 147 mm |
| Weight Kg | 1,75 Kg |
